CK6140 Overall Flat Hard Rail

High processing accuracy and stable processing quality

Key words:

Classification:

hard rail

Keyword： CK6140 Overall Flat Hard Rail

E-mail:

1300552380@qq.com

Message

Product Details

CK6140 Overall Flat Hard Rail Main Specifications

Name	Item	Unit	Parameter
Working Capacity	Maximum Spindle Diameter	mm	440
	Maximum Diameter on Sliding Plate	mm	320
	Chuck Size	in	10
	Distance Between Centers	mm	1000
	Total Width of Bed Guide Rail	mm	450
Spindle	Spindle Head Type	GB	A2-6
	Spindle Through Hole Diameter	mm	68/57/82
	Maximum Spindle Speed	r/min	2500
Main Motor	Main Motor Power	Kw	5.5
X Axis Rail	FL3208	mm	670
Z Axis Rail	FL4008	mm	1400
X/Z Axis	X/Z Axis Stroke	mm	380/950
X/Z Axis	X/Z Axis Rapid Traverse Speed	m/min	12/12
Tool Holder	Tool Bar Cross Section Size	mm	25X25
Tailstock	Sleeve Diameter	mm	75
	Effective Stroke of Sleeve	mm	150
	Tailstock Sleeve Taper Hole		MT5
Size	Overall Dimensions (Length x Width x Height)	mm	2800×1700x1750
Weight	Net Weight (Approx)	Kg

List of Main Spindle Components

Name	Size and Specifications	Place of Origin/Manufacturer
Front Bearing of Spindle	7218TBTB	Domestic
Rear Bearing of Spindle	7216DBB	Domestic
X Axis Screw	FD3208	Qidong, Jiangsu
Z Axis Screw	FD4008	Qidong, Jiangsu
X Axis Fixed End Bearing	760205	Domestic
Z Axis Fixed End Bearing	760205	Domestic
X Axis Drive Motor	130
Z Axis Drive Motor	130

Note: For the above brands, if there are inconveniences caused by suppliers (such as delivery delays, price adjustments, products not meeting requirements, etc.), our company may consider using other equivalent brands.
